輥徑×最度Roll Size(D/L)

610×1830

前輥線LineSpeed(M/Min)

31.6

前輥轉速FrontRollRPM(Min)

16.5

滾筒速比(前/後)Roll Ratio(Front/Back)

1:1.29*

一次投料Produce Weight (Once)

120 ~130KG

電機功率 Motor Power

160Kw-6P/

132Kw-8P*

重量Weight(KG)

25500KG

集裝箱容積Container Volume

45m³

安裝尺寸Dimensions (LXWXH)

L6100 x w2050 × H2200

冷卻方式Cooling Mode

加壓冷卻旋轉接頭
Pressurized Cooling Rotating Joint

襯套Bush

軸承式
Bearing Type

材料接收器MaterialReceiver

不繡銅材質
Stainless Steel Material

制動系統Emergency Stop

按鈕剎車和腳剎
Press Button Brake & Foot Brake

輔助系統 Transmission

低噪音齒輪箱齒輪
Low Noise Gear Box Gear
