輥徑×最度Roll Size(D/L)

550×1530

前輥線LineSpeed(M/Min)

28.29

前輥轉速FrontRollRPM(Min)

16.38

滾筒速比(前/後)RollRatio(Front/Back)

1:1.29*

一次投料Produce Weight (Once)

50 ~60KG

黿禨功率 Motor Power

110Kw-6P/90Kw-8P*

重量Weight(KG)

18500KG

集裝箱容積Container Volume

23m³

安裝尺寸Dimensions (LXWXH)

L5365 xW1946 ×H2193

冷卻方式Cooling Mode

加壓冷卻旋轉接頭Pressurized Cooling Rotating Joint

襯套Bush

軸承式Bearing Type

材料接收器MaterialReceiver

不繡銅材質Stainless Steel Material

制動系統Emergency Stop

按鈕剎車和腳剎Press Button Brake & Foot Brake

輔助系統 Transmission

低噪音齒輪箱齒輪Low Noise Gear Box Gear
